When should we choose a roller hearth kiln or a belt furnace in the microelectronics industry?

In the microelectronics industry, selecting the right sintering equipment is crucial for sintering processes. Both roller hearth kilns (RHK) and belt furnaces offer unique advantages, catering to different manufacturing requirements. Here's a balanced comparison highlighting the strengths of each:

Roller Hearth Kilns (RHK):

1. Superior Performance Metrics: Roller hearth kilns offer performance metrics that match or even surpass those of traditional belt furnaces. They are capable of replacing belt furnaces in the thick film, LTCC sintering industry.
2. Unique Design Features: Roller hearth kilns utilize roller bars instead of belt conveyors, eliminating the introduction of metal into the furnace chamber. This design enhances thermal shock stability and allows for convenient start-stop operations.
3. Enhanced Interior Lining: The interior lining of roller hearth kilns is designed for high strength, reducing the risk of powder material fallout and contamination of products. Additionally, special treatments applied to the heating element surfaces prevent oxidation and flaking.
4. Productivity Boost: Roller hearth kilns boast a productivity factor of 1.3 compared to belt furnaces of similar size, making them a cost-effective option for high-volume production.

Rollers offer flexibility in furnace operations. Each roller can operate independently, allowing for precise control over movement patterns within the furnace. Whether it's adjusting speed, or pausing at specific zones, roller hearth kilns enable tailored sintering processes to meet diverse application requirements.

• High-Precision Transmission
• Up to ±1°C Across Section Temperature Uniformity
• Product Displacement 3mm
• Air/Oxygen/Nitrogen Capability
• Adjusting speed, or pausing at specific zones
• 1.3 times productivity

Belt Furnaces:

1. Proven Reliability: Belt furnaces have been widely used in the microelectronics industry for decades, demonstrating proven reliability in various sintering applications. Their robust construction and straightforward operation make them a trusted choice for manufacturers worldwide.
2. Cost-Effective Solution: Belt furnaces are often a cost-effective solution for small to medium-scale production runs and development work. Their relatively lower initial investment cost and simplified maintenance contribute to their affordability for businesses of all sizes.
3. Efficient Heat Transfer: Belt furnaces feature efficient heat transfer mechanisms, ensuring uniform heating and precise temperature control throughout the sintering process. This results in consistent sintering outcomes and high-quality product outputs.
4. Ease of Integration: Belt furnaces can be seamlessly integrated into existing production lines, allowing for smooth process transitions and minimal disruption to manufacturing operations. Their compatibility with various automation systems further enhances production efficiency.

• 1150°C Maximum Temperature Rating
• Belt Speed Control
• ±1°C Cross Belt Uniformity
• ±1°C PID Control Precision
• ±1.5 °C Cross Belt Uniformity
• Atmosphere Available

In conclusion, both roller hearth kilns and belt furnaces offer distinct advantages in the microelectronics industry, catering to different production requirements and preferences. While roller hearth kilns excel in high-purity sintering processes and offer enhanced precision and productivity, belt furnaces provide proven reliability, versatility, and cost-effectiveness for a wide range of applications. Manufacturers should carefully evaluate their specific needs and objectives to determine the most suitable sintering equipment for their operations.
